How do you upgrade the storage in the Aluminum 'Unibody' Mac mini models? What type of hard drive(s) or SSD(s) do they each support? There are five different lines of Aluminum 'Unibody' Mac mini systems - the 'Mid-2010,' 'Mid-2011,' 'Late 2012', 'Late 2014' and 'Late 2018' - with notable differences in supported storage. Photo Credit: Apple, Inc.

(Non-Server Mid-2010 - Left, Mid-2011 & Late 2012 - Right) Identification Help If you're not sure which Aluminum Mac mini model you have, the optical drive equipped 'Mid-2010' models and current 'Late 2018' 'Space Gray' models should be easy to spot (at least for now), but many models in between these lines are more of a challenge. All Aluminum Mac mini models can be precisely identified by the in software or externally by, and more details about specific identifiers are provided in EveryMac.com's extensive section. To locate the model identifier in software, select 'About This Mac' under the Apple Menu on your computer and click the 'More Info.' If the Mac mini is running OS X 10.7 'Lion' or later, you will need to click the 'System Report' button after clicking 'More Info.'

For the pre-Late 2014 Mac mini models, the EMC number is visible upon removing the bottom 'spin off' panel to the right of the memory slots (when the ports are facing you). It is on the bottom of the 'Late 2014' and 'Late 2018' models toward the ports. As always, EveryMac.com has hand documented the model identifiers and EMC numbers unique to each model, which are most easily visualized as a chart: Alu. Mac mini Subfamily Model ID EMC No. Mid-2010 Mid-2010 Mid-2010 Mid-2011 Mid-2011 Mid-2011 Mid-2011 Late 2012 Late 2012 Late 2012 Late 2012 Late 2012 Late 2014 Late 2014 Late 2014 Late 2014 Late 2018 Late 2018 Late 2018 EveryMac.com's feature - as well as the - also can identify these models by their. Storage Types, Dimensions & Requirements Regular 'Mid-2010' Aluminum 'Unibody' Mac mini models, which have optical drives, support a single 2.5-inch, 9.5 mm tall, 3 Gb/s Serial ATA (SATA Revision 2.0) hard drive or SSD (or two storage drives if you remove the optical drive).

The oddball supports two storage drives of the same type (and no optical drive). All 'Mid-2011' and 'Late 2012' models hold two 2.5-inch storage drives with the same 9.5 mm height restriction, but have faster 6 Gb/s Serial ATA (SATA Revision 3.0) support. The non-server 'Mid-2011' and 'Late 2012' models, which only ship with one hard drive by default, a second hard drive or SSD is supported, but one has to purchase the cable needed to attach the drive to the board before installation is possible. A user from the forums first determined that the needed part is referred to as the 'Bottom Hard Drive Flex Cable' (Apple Part Number 922-9560) and successfully installed a second drive. More recently, site sponsor began offering a ' upgrade kit for the Aluminum Mac mini models that includes everything needed to perform this upgrade - the cable, drive bracket, precisely sized screwdrivers and screws - in one convenient package.

The 'Late 2014' models have a 6 Gb/s Serial ATA (SATA Revision 3.0) connector for a 2.5-Inch hard drive or SSD in addition to a proprietary PCIe connector for a 'blade' SSD. As first noted by site sponsor, the cable to connect this SSD to the PCIe connector is not present unless the system is configured with a 'Fusion Drive' at the time of initial purchase. However, it is possible to buy this cable later. Accordingly, as documented by site sponsor, this 'PCIe SSD Cable Connector' is part number 821-00010-A. The current 'Late 2018' models have onboard storage and it cannot be upgraded at all after the initial system purchase.

These details can be helpfully summarized accordingly: Alu. It is hoped that by watching the videos you should be able to determine whether or not you feel comfortable performing the upgrade yourself or if you would rather hire a professional. Mac mini Hard Drive or SSD Purchase Options In theory, just about any hard drive or SSD that meets the minimum requirements should work in the Mac mini. However, it always is best to buy from a trusted company with Mac knowledge for the most trouble-free experience.

Connector

Sale 821-00010-a Ssd Pcie Flex Cable Connector Adapter For Macbook Pro

In addition to the convenient storage for applicable Aluminum Mac mini models, sells hard drives and SSDs and offers an installation, as well. In the UK and Ireland, site sponsor sells Mac mini with free shipping.

The company provides flat rate shipping to France, Germany, and Switzerland and inexpensive shipping for all of Europe, too. In Australia, site sponsor sells Mac mini compatible SSDs, in addition to memory, with fast, flat-rate shipping Australia-wide. In Southeast Asia, site sponsor sells Mac mini compatible storage, as well as memory, with free delivery - and optional upgrade service - in Singapore and flat rate shipping to Hong Kong, India, Indonesia, Malaysia, the Philippines, Thailand, Vietnam and South Korea.

Also see:. do you upgrade the RAM in the Aluminum 'Unibody' Mac mini models?

What type of RAM do they use? How much RAM do they actually support?. do you upgrade the hard drive in the Polycarbonate Intel Mac mini models? What type of hard drive do they support? Is it possible to replace the optical drive with a second hard drive?.

The M.2 NVMe + M.2 SATA SSD PCIe x4 Adapter is a unique product with 2 very different M.2 Slot. It can offer the fastest boot or data access thru the NVMe SSD and at the same time provide very fast storage through the M.2 SATA SSD.

Sale 821-00010-a Ssd Pcie Flex Cable Connector Adapter For Mac Pro

It provides the link between PCIe 4 lanes of data path straight to the NVMe SSD resulting in super-fast data transfer and another M.2 interface for your M.2 SATA SSD. This adapter allows for flexible installation of an M.2 (NGFF) of different size like 42, 60, or 80mm in length with varying capacity.
